Motorola DLR1020: Discontinued — Replaced by the Motorola CURVE DLR110
Discontinued Model • License-Free 900 MHz • 2 Channels • See the Recommended Replacement Below
⚠ This Radio Has Been Discontinued
The Motorola DLR1020 is no longer manufactured or available for purchase. For new orders we recommend its direct replacement, the Motorola CURVE DLR110 — the current license-free 900 MHz digital business radio that keeps the same FHSS platform in an updated, ergonomic build. Already running DLR1020 radios and need to expand or upgrade a fleet? Call our team at 1-800-507-6002.
The Motorola DLR1020 was a license-free 900 MHz ISM digital two-way radio built for compact, discreet, on-site communication. Using Frequency Hopping Spread Spectrum (FHSS), it delivered secure, interference-free audio with no FCC license required — making it a popular choice across retail, hospitality, events, education, and healthcare. Today that role is filled by the current Motorola CURVE DLR110.
What the DLR1020 Offered
License-Free 900 MHz
Ran on the 900 MHz ISM band with no FCC license required — ready to use straight out of the box.
FHSS Digital Security
Frequency Hopping Spread Spectrum delivered secure, interference-free audio that resisted eavesdropping and channel congestion.
Compact & Discreet
Lightweight, pocket-sized design ideal for retail, hospitality, events, education, and healthcare staff.
Private Reply & Direct Call
Streamlined one-to-one calling features for faster, more focused team collaboration.
All-Day Battery
Up to 14 hours of runtime to cover a full shift on a single charge.
Wide In-Building Coverage
Approximately 300,000 sq ft or 20 floors of in-building range.
Rugged Build
MIL-STD 810 C–G tested with an IP52 rating for dust and water resistance.
Technical Specifications
| Feature | Specification |
|---|---|
| Model | Motorola DLR1020 (Discontinued) |
| Power Output | 1 Watt |
| Channels | 2 Channels |
| Band / Frequency Range | 900 MHz ISM FHSS |
| Technology | Digital |
| License Required | No License Required |
| Coverage | 300,000 sq ft / 20 floors |
| Battery Life | 14 Hours |
| Key Features | Frequency Hopping Spread Spectrum (FHSS), Private Reply, Direct Call |
| Durability | MIL-STD 810 C, D, E, F, G |
| IP Rating | IP52 |
| Encryption | No |
| Warranty | 2 Year Manufacturer Warranty |
| Status | Discontinued — replaced by the Motorola CURVE DLR110 |
Recommended Replacement: Motorola CURVE DLR110
The Motorola CURVE DLR110 is the direct, current-generation successor to the DLR1020. It keeps the same license-free 900 MHz FHSS digital performance the DLR-series was known for — secure, interference-free audio with no FCC license — in an updated, ergonomic build. Browse the wider license-free two-way radios range, or compare the full lineup of business two-way radios if you need a different power level or channel count.
See the Recommended Replacement →
Frequently Asked Questions About the Motorola DLR1020
• Is the Motorola DLR1020 discontinued?
Yes. Motorola has discontinued the DLR1020, and it is no longer manufactured or available for purchase. The recommended current replacement is the Motorola CURVE DLR110.
• What radio replaced the Motorola DLR1020?
The Motorola CURVE DLR110 is the direct replacement — the same license-free 900 MHz FHSS digital platform in an updated, ergonomic design.
• Did the Motorola DLR1020 require an FCC license?
No. The DLR1020 operated on the license-free 900 MHz ISM band, so no FCC license was required. Its replacement, the license-free CURVE DLR110, works the same way.
• Can you help upgrade an existing DLR1020 fleet?
Yes. Call our team at 1-800-507-6002 and we'll help you migrate to the CURVE DLR110 or plan a fleet upgrade.
Product details:
| Brand | Motorola Solutions |
| Product Type | Radio |
| SKU | DLR1020 |
Full spec sheet: contact us at 1-800-507-6002
